Detail Agen Gear Pump Koshin GL-50-5
Gear Pump Koshin GL-50-5
Agen Gear Pump Koshin GL-50-5
- Safety by pass function protects pump
- for oil transfer
Applications
- kerosene
- machine oil
- heavy oil
- light oil
Spesifikasi
Model : GL-50-5
Performance Curve No : 11
Connection Dia : 50 mm ( 2")
Power : 3.7 kW
Poles : 6P
Max Pressure MPa : 0.5
Max Pressure kg/cm :5
Delivery Volume 60 Hz ( 1800 rpm ) : 200 L/min ( 52 USG/min )
Delivey Volume 50 Hz ( 1500 rpm ) : 165 L/min ( 43 USG/min )
Material of Housing : FC
Coupling : JIS
Pump Shaft Dia : 22 mm
Net Weight : 26 kg ( 57 lbs )
Gross Weight : 27 kg ( 60 lbs )
Dimension LxWxH (mm) : 318x258x220
Packing unit : 1
